AJ PowerCube P5A - Battery Module Date

File version: V1.0
Page 33 of 33
8.6 Battery Module Data
Technical Parameters
Model
PowerCube P5A
Battery Type
LiFePO4
Energy
5120Wh
Capacity
100AH
Rated Voltage
51.2V
Working Voltage Range
40～58.4V
Max Charge Current
100A
Max Discharge Current
100A
DOD
100%
Max Parallel Quantity
6
Designed Life-span
6000 cycles
Operating Temperature
Charge：0～60℃
Discharge：-10～60℃
Operation Humidity
5～95%
Nominal Operation Altitude
＜3000m
IP Rating
IP65
Installation Method
Stacking
Net Weight
46.3kg
Dimension (L*W*H)
635*400*192 mm
Warranty
10 years
192mm
400mm
635mm
