4 85
When removing the control unit from the retaining plate [21], do not ever hold it by the
speed dial [16]. Hold it only by the handle (see diagram opposite). This prevents you from
switching on the control unit unintentionally.
Information for left-handed persons
• Unless you specify otherwise when ordering the e-motion, the retaining plate [16] is mounted on the right-
hand side of the wheelchair as standard.
• The Mobility app allows the control unit to be switched to left-handed use at any time. Please consult the
operating manual for the e-motion Mobility app for further information in this regard.
3. Setting the control unit
If desired or necessary, the position of the display [23] can be adjusted.
• Switch off both e-motion wheels completely (see the e-motion M25 operating manual).
• Open the cover [18] of the control unit.
•
Loosen the three screws [25] on the back of the control unit by not more than half a turn. To this end, use
an Allen key, size 2.5.
• Turn the ring [24] until the display [23] is in the desired position. Then carefully tighten the three
screws [25] until the ring [24] can no longer be turned.
• Close the cover [18] of the control unit.
25
25
23
24
