Alarm Data Value/Meaning
AID Type 112SA1L-shelf-slot-{L1, C1}
112SCA1-shelf-slot-{L1, C1}
112SCX10-shelf-slot-L1
112SX10L-shelf-slot-L1
11DPE12-shelf-slot-{L1, L2}
11QPA4-shelf-slot-{L{1-4},C{1-4}}
11STAR1-shelf-slot-{L1, C1}
11STMM10-shelf-slot-{L1}
11STMM10-shelf-slot-{C1-10}
11STGE12-shelf-slot-{L1}
43SCX4-shelf-slot-L1
43STA1P-shelf-slot-{L1, C1}
43STX4-shelf-slot-L1
43STX4-shelf-slot- C{1-4}
43STX4P-shelf-slot-L1
43STX4P-shelf-slot-{C1-C4}
4DPA4-shelf-slot-{L1, L2}
4DPA4-shelf-slot- {L1, L2}
Effect on Service NSA
Alarm Entity Type 112SA1L, 112SCA1, 112SCX10 and
112SX10L: OTU4
43SCX4 and 43STA1P: OTU3
All other AIDs: OTU2
Description Server Signal Failure - OTU
Corrective Action Proceed to “SSF” (p. 2-294).
Alarm and condition details SSF
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
