Chassis Status LEDs
The chassis provides a series of status LEDs located on the front panel. These LEDs offer basic status
information for hardware operation and port link and activity status.
LED State Description
OK Solid Green
Blinking Green
Solid Amber
System Diagnostics and AOS bootup OK
System Diagnostics and AOS in progress
(i.e., performing diagnostics or booting)
System Diagnostics and/or AOS bootup failed
VC Solid Green
Solid Amber
Blinking Amber
Off
This unit is the master unit
This unit is a slave unit
Identifies unit number by the number of
blinks.
This unit is in shutdown mode or is not part of
a VC.
PS1/PS2 Solid Green
Solid Amber
Off
Power supply functioning normally.
Power supply not functioning normally.
Power supply not present.
10/100/1000 Port LEDs Solid Green
Blinking Green
Valid port link
Valid port link with activit
SFP 100/1000Base-X
Port LEDs
Solid Green
Blinking Green
Valid port link
Valid port link with activity
SFP+ Port LEDs Solid Green
Blinking Green
Valid 1G/10G port link
Valid 1G/10G port link with activity
