Alcatel-Lucent OmniSwitch 6570M - Power Supplies; Internal Power Supplies

Power Supplies Chassis and Power Supplies
page 3-16 OmniSwitch 6570M Hardware Users Guide December 2022
Power Supplies
OmniSwitch 6570M switches can use the following power supplies:
Internal Power Supplies
Model Chassis Supported
Internal Power Supply (See page 3-16) OS6570M-12, OS6570M-12D
OS6570M-12 AC Power Supply (DA-60Z12)
(See page 3-17)
OS6570M-12
OS6570M-12D DC Power Supply (DDR-30L-12)
(See page 3-18)
OS6570M-12D
OS6570M-U28 AC Power Supply (PS-150W-AC)
(See page 3-19)
OS6570M-U28
OS6570M-U28 DC Power Supply (PS-150W-DC)
(See page 3-20)
OS6570M-U28
Model Internal AC Power Supply
Description Internal AC 65W power supply
Models Supported OS6570M-12
Input 100-240V, 50-60Hz
Output 12V/5.42A (65W)
Model Internal DC Power Supply
Description Internal DC 30W power supply
Models Supported OS6570M-12D
Input 36-72VDC
Output 12V/5.42A (30W)
