Installing Expansion Modules OmniSwitch 6450 Chassis and Hardware Components
page 3-38 OmniSwitch 6450 Hardware Users Guide September 2015
4 When the module is seated in the chassis slot, hand tighten the thumb screws at the left and right sides
of the module’s front plate.
5 Install transceivers and connect network cables as required. Refer to the OmniSwitch 6250/6450
Transceivers Guide for additional information.
Note. If installing the OS6450-XNI-U2 stacking module, refer to the Chapter 6, “Managing OmniSwitch
6450 Stacks” for information on stacking cable requirements.
