MicrowaveradiorelaylinkZENITH80 
 11/52 1.2
2.2.1 InputConnectors
Powersupplyconnectoronthefrontpanel

Theconnectioncableforthisconnectorendswiththesockettype1777989Phoenix(0395340002Molex).
TypedesignationcorrespondstothePhoenix(Molex)catalogue.

RJ45connectorsforuserlineinput
Userlines2and3
Wiring Pins Description
1 A+
2 A‐
3 B+
4 C+
5 C‐
6 B‐
7 D+

8 D‐
Table1 RJ45connectorwiring–userlinesLine2aLine3

TheAutoMDIXfunctionassuresswitchingofRXandTXasneeded.
