aldes EasyVEC C4 User Manual

31
EN
Category
Adress
(Decimal)
Adress
(Hexa)
Data
Size
(Words)
Read Write
Comments
(0x03) (0x10)
Identification
1 $1 Machine ID code 2 x SAP code
3 $3
Aldes serial
number
4 x
12 $C Software version 1 x
20 $14
Back-up order
Parameters
1 x x
EasyVEC
®
: Storing $1213, Reset C4:
$5452
21 $15 Box fan number 1 x
34 $22 Product ID 1 x x
BMS Ventilation
Operating mode 256 $100 Control mode 1 x x
Constant pressure self-balancing = 12
Constant pressure self-balancing = 12
Constant pressure
humidity-controlled = 13
Constant pressure TFlow = 14
Constant airflow = 1001
Constant speed = 2
Rising curve auto = 1002
Rising curve hygro = 1003
Rising curve TFlow = 1004
Rising curve Expert = 1005
0-10 V = 1006
Operating
setting
272 $110
Exhaust Flow
setpoint
1 x x
274 $112
Extract Pressure
setpoint
1 x x
276 $114 speed setpoint 1 x x
284 $11C
Parameter 0-10V
U1
1 x x
285 $11D
Parameter 0-10V
U2
1 x x
286 $11E
Parameter 0-10V
V1
1 x x
287 $11F
Parameter 0-10V
V2
1 x x
288 $120 Parameter P1 1 x x
289 $121 Parameter P2 1 x x
291 $123 Nbr. Eyes 1 x x
292 $124 gas option 1 x x
Main entries
Supply 337 $151
Power supply
voltage
1 x
0-10V entry 338 $152 0-10V input 1 x
C4 Mode 366 $16E Mode C4 state 1 x 0 = shutdown, 2512 = active
Errors
384 $180 Current error code 1 x
386 $182
Previous error
code
1 x
388 $184 N-2 error code 1 x
390 $186 N-3 error code 1 x
392 $188 N-4 error code 1 x
394 $18A N-5 error code 1 x
396 $18C N-6 error code 1 x
398 $18E N-7 error code 1 x
400 $190 N-8 error code 1 x
Machine reboot 65534 $FFFE Card restart 1 x
If 0xFFFE sent, the card then is
reset and the commissioning will be
eliminated
