Replacing the shaving foil unit
If the shaving foil unit is damaged, it must be promptly
replaced. We generally recommend that you replace the
shaving foil unit after 12 months of daily use.
1. Depress both release buttons
4
to release the
shaver head
2
(see fig. A and E).
2. Pull the shaver head up and off.
3. Push the hooks
15
on the left and right of the shav-
ing foil unit
16
into the shaver head frame
17
(see Fig. K and L)
4. Pull the shaving foil unit down and out of the shaver
head frame (see fig. L).
5. Dispose of the used shaving foil unit as described in
the chapter “Disposal”.
6. Place the new shaving foil unit in the shaver head
frame so that:
a. the guide braces inside the
shaver head frame
17
extend into
the guide grooves outside along the
shaving foil unit
16
and
b. the recess in the shaving foil unit
16
is
on the same side as the recess inside the
shaver head frame
17
(see fig. K and L).
7. Place two fingers on the back side of the integrated
trimmer.
