34
Operation
Setting the cutting depth
Use the crank (
32
) to turn the saw blade (
31
) out of the saw table
(
1
) and lower it into the saw table. Adjust it to the depth you
require as follows:
• Increasing the cutting depth:
Turn the crank clockwise so that the saw blade is moved out of
the saw table.
• Reducing the cutting depth:
Turn the crank counterclockwise so that the saw blade is lowered
into the saw table.
Setting the cutting angle (Fig. 23)
1. Turn the locking screw (
38
) approx. one revolution
counterclockwise to slacken it.
2. Use the crank wheel (
39
) to adjust the cutting angle to the
angle you require on the angle scale (
40
).
3. Turn the locking screw clockwise to tighten it and secure the saw
blade (
31
) at the desired angle.
Parallel stop
Stop height
The stop rail (
22
) for fitting on the parallel stop (
20
) has two
different guide faces (high and low). For thick material you must
use the stop rail stood on edge (with a workpiece thickness of over
25mm), for thin material (with a workpiece thickness of less than
25mm) you must use the stop rail lying flat.
To turn the stop rail, proceed as follows:
1. Slacken the knurled nuts on the parallel stop by turning them
several revolutions.
2. Pull the stop rail off the parallel stop.
3. Turn the stop rail into the required position.
Layout_F_TS_2000_1_UK_SPK7.indd 34Layout_F_TS_2000_1_UK_SPK7.indd 34 23.06.2020 14:29:3723.06.2020 14:29:37
