15
AFTER SALES SUPPORT
Getting to know your appliance
GB
0333 32 13 106
IRE
1 800 992508
www.medion.co.uk
GB IRE
Electrical connections
Only used the supplied foot pedal model ES01FC.
Power switch
Mains socket
Mains cable
Foot pedal
Connection
Mains cable
Connection cable
Foot pedal
Connection
Foot pedal
CAUTION!
Risk of injury!
Inadvertent operation of the foot pedal can lead to a risk of
injury.
− Once you have fi nished working or before you start
maintenance, always turn off and unplug the machine.
 Connect the foot pedal using the connector for the foot pedal to the
sewing machine.
 Connect the plug of the mains cable supplied into the plug housing
on the machine, and then connect the power cable of the machine
to the mains socket.
 Turn the machine on using the power switch
22
. The power switch
turns both the sewing machine and the sewing light on.
Controlling the sewing speed
The sewing speed is controlled by the foot pedal. The sewing speed can
be changed by applying more or less pressure to the foot pedal.
Attaching and removing the table extension
The machine is supplied with an attached work table.
 The table extension is removed by pushing it carefully to the left.
 To attach the table extension, carefully place the table extension
on to the machine and push it to the right until it audibly clicks into
place.
15694 EN ALDI UK_IRE Content MSN 5005 3188 final.indd 1515694 EN ALDI UK_IRE Content MSN 5005 3188 final.indd 15 12.05.2016 07:00:1912.05.2016 07:00:19
