210cc 4 stroke Petrol High Pressure Washer
AFTER SALES SUPPORT
(toll free) MODEL No.: SHW196 • 06/2019 9885
e-mail: info.aldi@positecgroup.com
AUS
21
1300 889 028
AUS
To coil the 10m pressure hose (6) onto the hose reel (4)
(See fig. F4-F7):
1) Place the connected hose inlet with the hose reel outlet onto the
reel (4) as shown in fig. F4.
2) Turn the hose reel handle (5) clockwise, at the same time, slowly coil
the hose (6) round and round onto the reel (4) evenly, until the 10m
pressure hose (6) is totally coiled onto the reel (4).
c
F1
F2
F3
d
F7
F5
F4
F6
HOSE SHOULD EXIT VIA
THE REAR OF THE UNIT
REAR
