Pack contents⁄device parts
1
Saw table
29
Splitting wedge
2
Table insert (with fixing screws, 2×)
30
Waste bag
3
Guide groove (saw table)
31
Eccentric lever (parallel guide)
4
Right table width extension
32
Viewing window (parallel guide)
5
Left table width extension
33
Parallel guide
(with carriage screw and knurled nut, 2×)
6
Table length extension
34
Guide rail (cross guide)
7
Long table support, 2×
35
Knurled knob (cross guide)
8
Short table support, 4×
36
Cross guide
(with carriage bolt and knurled nut, 2×)
9
Centre brace, 4×
37
Stop rail (cross guide)
10
Stop rail (parallel guide)
38
Push stick holder
11
Push stick
39
Clamping plate (for securing the splitting wedge)
12
Tip guard, 2×
40
Clamp bolt (for securing the splitting wedge)
13
Support leg, 4×
41
Pressure disc (saw blade)
14
Rubber foot, 4×
42
Outer saw blade flange
15
Carriage bolt, 8×
43
Hexagon bolt (saw blade)
16
M6×12 mm hexagon bolt, 10×
44
Saw blade
17
M6×16 mm hexagon bolt, 14×
45
Rail with scale (saw table)
18
Spring washer, 24×
46
Locking knob
19
Flat washer, 34×
47
Angle scale (cutting angle)
20
Hexagon nut, 18×
48
Crank wheel
21
Large washer, 8×
49
Crank
22
Ring spanner
50
Power switch (green: I /red: 0)
23
Saw blade key
51
Battery compartment cover (laser)
24
AF10 spanner
52
Laser switch (laser on: /laser off: 0)
25
Adapter (extractor connection for the
saw table)
53
Batteries (laser), 2× 1.5 V AAA/LR03
26
Saw blade guard
54
Battery compartment (laser)
27
Lens head screw (saw blade guard)
55
Long hole (splitting wedge)
28
Laser
