Alesis Vortex Wireless 2 Service Manual

15
Level Part Number Description Specification Usage UOM Remark
+ 1020109200
Unpacking part of the electronic
keyboard
LQVL 1.00000 SET
++ 1020405430 Top cabinet ASSY LQVL 1.00000 SET
+++ 201030725 Top cabinet
HIPS injection black spray oil black silkscreen
White and Pantone Process Cyan C PU
1.00000 PCS
++++ 201010215 Top cabinet HIPS injection black N/A 1.00000 PCS
+++++ 298020001 Plastic HIPS 0.45835 Kg
+++ 215010129 Touch sheet bracket ABS injection black 1.00000 PCS
++++ 298010001 Plastic ABS 0.00927 Kg
+++ 299010186 Fader Cap ABS injection black 1.00000 PCS
++++ 298010001 Plastic ABS 0.00103 Kg
+++ 631020168 Black Velvet paper 17*14*0.3mm with Double-sided adhesive strips 1.00000 PCS
+++ 299010187 Fader Cap rod ABS injection black 1.00000 PCS
++++ 298010001 Plastic ABS 0.00103 Kg
+++ 218010084 Fader Light Guide LQVL DL-2334 PC material White plastic bag toner: YS1801A 8.00000 PCS
+++ 1012401080 Pitch wheel ASSY LQVL 1.00000 SET
++++ 901990032 Hot-Melt Tape 11.2±2*300 yelLow Clarity 0.00010 Kg
++++ 3029900680 Nut M9 T=2mm Zn alloy 1.00000 PCS
++++ 213010080 Modulation wheel
ABS+TPE injection ABS transparent+TPE Black
N/A
1.00000 PCS
++++ 901010013
Stannum of cord sotder wire
(lead)
Sn-0.3Ag-0.7Cuφ1.0mm FLUX;2.2% 0.00090
ROL
L
++++ 901030129 FLUX TF-800H 20L/pail 0.01510 L
++++ 309070115 Modulation wheel spring
Spring wire ∮0.9mm inner ∮10.3mm Nickel-
plated
1.00000 PCS
++++ 628072059
Color Flat Cable with Cathode
Plug
L=150mm 26AWG UL1007 One side with
3PIN/2.54 anti-drop cathode plug Another side
strip and tin 3.5mm
1.00000 PCS
++++ 6110102260 Rotating Potentiometer
H111K-2 B10K(55°) L15FC*7(H10)(K)-0057
HongYu
1.00000 PCS
++++ 215010130 Pitch wheel bracket ABS injection black 1.00000 PCS
+++++ 298010001 Plastic ABS 0.00309 Kg
+++ 299010129 Fader cap ABS injection Pantone process black C N/A 8.00000 PCS
++++ 298010001 Plastic ABS 0.00052 Kg
+++ 629990394 Drum pad
Silica gel 30°Milk White 25% opaque top side
with black silkscreen
1.00000 PCS
+++ 629020492 Rubber button
Silicone SA50 Milk White painting Black Laser
Etch Graphics
1.00000 PCS
+++ 629020490 Rubber button Silicone SA50 Milk White silk-screen Black top 1.00000 PCS
+++ 301070004 screw PWB 3*6PWB Color Zn crisscross PWB 4.00000 PCS
+++ 301020014 Flat round head screws PB 3*8PB black crisscross head 2.00000 PCS
+++ 629020491 rubber button 4 group Silicone SA50 Milk White silk-screen Black top 1.00000 PCS
+++ 101011484002 Main Board ASSY LQVL 1.00000 SET
++++ 6190300350 3bit digital LED
E1-3040ASB3-P8_3 0.4inch Blue470nm
Common anode 3 x DP TH Strongbase
1.00000 PCS
LED
++++ 6280100790 Masculine connector 20Pins/2.00mm 2*10 straight feet DIP 1.00000 PCS
J8
++++ 628010084 Masculine connector
10PIN*2 straight feet DUAL ROW WITH BOX
HEADER
1.00000 PCS
J7
++++ 6280103830 Masculine connector 8Pins/2.00mm 2*4 straight feet DIP 2.00000 PCS
J3 J4
++++ 628010348 Mascoline connector 2Pin/2.0mm Pitch single line straight 1.00000 PCS
J1
++++ 628010291 Masculine connector
4Pins/2.00mm single line Straight foot Belt
buckle card
1.00000 PCS
J10
++++ 628010313 Mascoline connector
8Pins/2.54mm pitch single line straight prevent
fall off
1.00000 PCS
J2
++++ 628010132 Masculine connector 8PIN/2.0mm single line straight feet 1.00000 PCS
CN2
++++ 6110200540 Slide Potentiometer
H3043N1-2 FC B10KA L5B(M)(J4)
Travel=30mm L=5mm HongYu
8.00000 PCS
FD1-FD8
++++ 101011485002 Main Board ASSY(SMD Part) LQVL 1.00000 SET
+++++ 506070134 PCB Dual layer FR4 1.6mm
LQVL Main Board REV3 FR4 Pad with ENIG
Green oil White Silkscreen 299*57*1.6mm
1.00000 PCS
+++++ 603010226 CAP CERAMIC SMD 0.01uf/50V +5% -5% 0603 NPO SMD 1.01000 PCS
C19
+++++ 603010116 CAP CERAMIC SMD 1000pf/50V +5%-5% 0603 NPO 1.01000 PCS
C83
+++++ 603010019 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0603 X7R 37.37000 PCS
C3 C4 C5 C7-10 C12-13 C15
C20-24 C26 C31-39 C48 C52
C60 C63 C70-72 C84 C91
C94 C96 C115
+++++ 603010231 CAP CERAMIC SMD 0.1uf/50V +10%-10% 0402 X7R 4.04000 PCS
C1 C2 C11 C14
+++++ 603010257 CAP CERAMIC SMD 10uf/16V +10%-10% 0603 X5R Yageo 1.01000 PCS
C95
+++++ 603010208 CAP CERAMIC SMD 18PF +5%-5% 50V 0603 COG 2.02000 PCS
C17-18
+++++ 603010233 CAP CERAMIC SMD 1uF/25V ±10% X5R 0402 SMD 3.03000 PCS
C6 C69 C73

Alesis Vortex Wireless 2 Specifications

General

Product color	Black, White
Volume control	Touch
Knobs color	Black
Control type	Buttons, Sensor
Number of pads	8
Backlight color	Multicolor
Backlight buttons	Yes
MIDI-keyboard number of keys	37 keys
Interface	USB
Bundled software	Hybrid 3, Loom 2, Vacuum Pro & Xpand! 2 from AIR Music Tech, TimewARP 2600 from Way Out Ware & Ableton Live Lite
Battery type	AA
Number of batteries supported	4
Minimum RAM	4000 MB
Minimum processor	Dual Core 2GHz, Intel Core i5/i7
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 7
