Alesis Vortex Wireless 2 Service Manual

Parts List
16
+++++ 603010225 CAP CERAMIC SMD 22uf/10V +20% -20% 0603 SMD X5R 7.07000 PCS
C27 C107-C112
+++++ 603010004 CAP CERAMIC SMD 100pf/50V +5% -5% 0603(NP0) SMD 32.32000 PCS
C28-30 C43-47 C50-51 C53
C56-59 C62 C64-68 C74-C76
C78-81 C97 C103-C105
+++++ 603010157 CAP CERAMIC SMD 100pf/50V +10%-10% 0402 SMD 10.10000 PCS
C98 C99 C117-121 C124-126
+++++ 603020038 CAP ELECT SMD 470uf/6.3V +/-20% 6.6*6.6mm Low ESR 2.01000 PCS
C16 C82
+++++ 603020007 CAP ELECT SMD 47uf/6.3V +/-20% 4*5MM 7.03500 PCS
C40 C49 C61 C86 C87 C90
C113
+++++ 603030025 CAP Tantalum SMD 22uf/10V+10%-10% A 3.2*1.6 3.01500 PCS
C88 C89 C93
+++++ 603030017 Cap Tantalum ELECT SMD 10uf/6.3V+10%-10% SIZE:2012 1.00500 PCS
C92
+++++ 606010033 Ferrite Bead SMD
HCB1608KF-331T20 2A 330R@100MHZ 0603
TAI-TECH
3.03000 PCS
L3 L8 R17
+++++ 6060100400 Ferrite Bead SMD
BLM15AG102SN1D Ferrite Chip Bead
1kOhm@100MHz 300mA 0402 Murata
10.05000 PCS
FB1-6 FB41-44
+++++ 6060100200 Ferrite Bead SMD BLM18BD102SN1D 1000ohm 0.1A 0603 39.39000 PCS
FB10-40 FB45-52
+++++ 6060100290 Ferrite Bead SMD
BLM18AG601SN1D FERRITE 600R@100MHZ
0603
2.02000 PCS
FB53 FB54
+++++ 6040100310 Inductor Ferrite SMD
INDUCTOR 2.2uH 20% 4*4MM 1.8A “MURATA”
LQH44PN2R2MPOL
1.00500 PCS
L2
+++++ 602010001 Resistor SMD 0 ohm(1/16w)+1%-1% 0603 3.03000 PCS
R16 R19 FB9
+++++ 602010645 Resistor SMD 0 ohm(1/16w)+1%-1% 0402 2.02000 PCS
FB7 FB8
+++++ 602010112 Resistor SMD 3.3K ohm(1/16w)+1%-1% 0603 1.01000 PCS
R15
+++++ 602020008 Resistor metallic film SMD 0 ohm 1/2w ±1% 0207 1.00000 PCS
R18
+++++ 602010571 Resistor SMD 1.5K ohm(1/8w)+1%-1% 0603 1.01000 PCS
R1
+++++ 602010407 Resistor SMD 33K ohm(1/10w)+1%-1% 0603 1.01000 PCS
R5
+++++ 602010009 Resistor SMD 100 ohm(1/16w)+1%-1% 0603 5.05000 PCS
R7-8 R39-41
+++++ 602010644 Resistor SMD 100 ohm(1/16w)+1%-1% 0402 15.15000 PCS
R11-14 R25 R26 R36-38 R50
R51 R57 R67 R74-75
+++++ 602010393 Resistor SMD 10K ohm(1/10w)+1%-1% 0603 4.04000 PCS
R42-44 R72
+++++ 602010640 Resistor SMD 10K ohm(1/16w)+1%-1% 0402 3.03000 PCS
R4 R71 R73
+++++ 602010025 Resistor SMD 1M ohm(1/8w)+5%-5% 0603 1.01000 PCS
R2
+++++ 602010720 Resistor SMD 220K ohm(1/16w)-1%+1% 0402 Yageo 3.03000 PCS
R68-70
+++++ 602010551 Resistor SMD 33 ohm(1/10w) ±1% 0603 1.01000 PCS
R3
+++++ 602010144 Resistor SMD 4.7K ohm(1/16w)+1%-1% 0603 2.02000 PCS
R48-R49
+++++ 602010729 Resistor SMD 4.7K ohm(1/16w)+1%-1% 0402 Yageo 1.01000 PCS
R52
+++++ 602010150 Resistor SMD 47K ohm(1/16w)+1%-1% 0603 2.02000 PCS
R22 R23
+++++ 602010602 Resistor SMD 5.6K ohm(1/10w)+1%-1% 0603 1.01000 PCS
R21
+++++ 602030052 Resistor chain SMD 33 ohm(1/16w)+/-1% CRN164 NETWORK 4.02000 PCS
R9-10 R53-54
+++++ 602030020 Resistor chain SMD 4.7K ohm(1/16w)+5%-5% CRN164 3.01500 PCS
R45-47
+++++ 602030072 Resistor Array SMD
47K ohm(1/16W)(ARV242) +1%-1% 0603*4
Yageo
1.00500 PCS
R6
+++++ 602030030 Resistor chain SMD 47 ohm(1/16w) +/-5% 0603*4 2.02000 PCS
R55-56
+++++ 619010169 LED SMD
WEJT81BC-881-ZD Blue 0805 IV：150-
250mcd(10mA) Yongerjia
34.34000 PCS
PERSET- PRESET+
FD_LED1A-FD_LED1D
FD_LED2A-FD_LED2D
FD_LED3A-FD_LED3D
FD_LED4A-FD_LED4D
FD_LED5A-FD_LED5D
FD_LED6A-FD_LED6D
FD_LED7A-FD_LED7D
FD_LED8A-FD_LED8D
+++++ 6280200230 FPC connector FPC 1.0D-18PBX Locker 1.00500 PCS
J11
+++++ 608010004 Switch Diode SMD IN4148 SOP TYPE SMD 2.01000 PCS
D1-2
+++++ 6099900160 FET SMD
PMV32UP SOT-23 P-MOSFET 20V 4A
32mOhm “NXP”PMV32UP
3.01500 PCS
TR1-3
+++++ 6010107570 IC SMD
STM32F103R8T6 STM32 CORTEX-M3
MICROCONTROLLER LQFP64“ST”
1.00000 PCS
U1
+++++ 6010109700 IC SMD
RT8009GJ5 ADJUSTABLE TSOT-23-5 600MA
ADJUSTABLE SWITCHING REG“RICHTEK”
1.00000 PCS
U7
+++++ 6010108080 IC SMD 74HC165 TSSOP16 1.00000 PCS
U15-A
+++++ 6010110570 IC SMD
74HC238 INVERTED 3-TO-8 LINE
DECODER/DEMUX TSSOP-16 NXP
1.00000 PCS
U4
+++++ 6010105450 IC SMD 74HC164 8-B-SIP0 SHIFT REG NXP-TSSOP14 2.00000 PCS
U2 U5
+++++ 6010107870 IC SMD 74HC4051PW TSSOP16 NXP 2.00000 PCS
U3 U6
+++++ 6010111530 IC SMD M24C64-RDW6TP TSSOP8 ST 1.00000 PCS
U10
+++++ 606010042 Ferrite Bead SMD
121 OHM@100MHz 0402 200mA
EBMS100505A121 HongYEX
2.02000 PCS
L7 L9
+++++ 6010111600 IC SMD
SGM803-TXN3L/TR RESET
THRESHOLD:3.08V Open-Drain RESET Output
Reset time(type):240ms SOT-23 SGMICRO
1.00000 PCS
U15

Alesis Vortex Wireless 2 Specifications

General

Product color	Black, White
Volume control	Touch
Knobs color	Black
Control type	Buttons, Sensor
Number of pads	8
Backlight color	Multicolor
Backlight buttons	Yes
MIDI-keyboard number of keys	37 keys
Interface	USB
Bundled software	Hybrid 3, Loom 2, Vacuum Pro & Xpand! 2 from AIR Music Tech, TimewARP 2600 from Way Out Ware & Ableton Live Lite
Battery type	AA
Number of batteries supported	4
Minimum RAM	4000 MB
Minimum processor	Dual Core 2GHz, Intel Core i5/i7
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 7
