Alesis Vortex Wireless 2 Service Manual

17
Parts List
+++++ 602010021 Resistor SMD 100K ohm(1/16w)+1%-1% 0603 1.01000 PCS
R20
++++ 610070002 Crystal DIP 49S 6MHz (HC-49S) DIP 1.00000 PCS
XT1
++++ 603020007 CAP ELECT SMD 47uf/6.3V +/-20% 4*5MM 1.00000 PCS
C85
++++ 603020042 CAP ELECT SMD UT1A221M0605VG 220uf/10V 6.3*5.4 1.00000 PCS
C25
+++ 1019903220 Pad Board ASSY LQVL 1.00000 SET
++++ 1019903230
Pad Board ASSY（SMD Part）
LQVL 1.00000 SET
+++++ 6280200230 FPC connector FPC 1.0D-18PBX Locker 1.00000 PCS
J2
+++++ 6190101360 LED
Q3MB-MTB1-ZA3A2 PLCC4 Tricolor Black
Surface LED“AVAGO” Bin Numbers:U2X1T2-
AA or U2X1T1-AA
8.00000 PCS
PAD_LED1-8
+++++ 602010551 Resistor SMD 33 ohm(1/10w) ±1% 0603 4.00000 PCS
R1 R4 R7 R10
+++++ 602010009 Resistor SMD 100 ohm(1/16w)+1%-1% 0603 1.00000 PCS
R13
+++++ 602010217 Resistor SMD 51 ohm(1/16w)+1%-1% 0603 4.00000 PCS
R3 R6 R9 R12
+++++ 602010144 Resistor SMD 4.7K ohm(1/16w)+1%-1% 0603 1.00000 PCS
R14
+++++ 603010019 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0603 X7R 5.00000 PCS
C2 C3 C4 C8 C13
+++++ 603020023 CAP ELECT SMD 10uf/25V +/-20% 4*5.4mm 5.00000 PCS
C5 C6 C7 C9 C14
+++++ 6010105450 IC SMD 74HC164 8-B-SIP0 SHIFT REG NXP-TSSOP14 2.00000 PCS
U1 U5
+++++ 6010107870 IC SMD 74HC4051PW TSSOP16 NXP 1.00000 PCS
U2
+++++ 506020003 PCB Dual layer FR4 1.6mm
LQVL_Pad Board_V02 FR4 Pad with HASL
White silkscreen Green Oil Carbon
151*60*1.6mm
1.00000 PCS
+++++ 602010637 Resistor SMD 39 ohm(1/10w) ±1% 0603 4.00000 PCS
R2 R5 R8 R11
+++ 101990326 Left Button Board ASSY LQVL 1.00000 SET
++++ 628072055 Gray flat cable with cathode plug
L=290mm UL2651 26＃one side with 9PIN/2.0
anti-dropping cathode plug another side stripping
and tinnin
g
3.5m
1.00000 BAR
J1
++++ 619010168 LED DIP
WEJ3B4BC-AC6 Bule 3mm IV：2200-
3800mcd
(
20mA
)
Yon
g
er
j
ia
5.00000 PCS
LED1-LED5
++++ 101990327
Left Button Board ASSY(SMD
Part)
LQVL 1.00000 SET
+++++ 506990019 PCB Dual layer FR4 1.6mm
LQVL_Button_Left Board_V03 FR4 Pad with
HASL White silkscreen Green oil Printed carbon
71.8*43.7*1.6mm
1.00000 PCS
+++++ 608010004 Switch Diode SMD IN4148 SOP TYPE SMD 4.02000 PCS
D1-D4
+++ 1019903240
Right Button Board（ASSY）
LQVL 1.00000 SET
++++ 6280100790 Masculine connector 20Pins/2.00mm 2*10 straight feet DIP 1.00000 PCS
J2
++++ 628010232 Masculine connector
3Pins/2.54mm Pitch single line straight prevent
fall off
1.00000 PCS
J3
++++ 628010231 Masculine connector
2Pins/2.54mm Pitch single line straight prevent
fall off
1.00000 PCS
J5
++++ 628010263 Masculine connector
9Pins/2.00mm pitch single line straight prevent
fall off
1.00000 PCS
J1
++++ 628010110 Single-line PIN 3Pins/2.54mm single line DIP 1.00000 PCS
J4
++++ 619010168 LED DIP
WEJ3B4BC-AC6 Bule 3mm IV：2200-
3800mcd
(
20mA
)
Yon
g
er
j
ia
6.00000 PCS
LED1-LED6
++++ 1019903250 Right Button Board(SMD Part) LQVL 1.00000 SET
+++++ 506990020 PCB Dual layer FR4 1.6mm
LQVL_Button_Right Board_V03 FR4 Pad with
HASL White silkscreen Green oil Carbon
103.8*57.2*1.6mm
1.00000 PCS
+++++ 608010004 Switch Diode SMD IN4148 SOP TYPE SMD 6.03000 PCS
D1-D6
+++++ 602010001 Resistor SMD 0 ohm(1/16w)+1%-1% 0603 2.02000 PCS
R1 R2
+++++ 602010021 Resistor SMD 100K ohm(1/16w)+1%-1% 0603 1.01000 PCS
R3
+++++ 603020007 CAP ELECT SMD 47uf/6.3V +/-20% 4*5MM 1.00500 PCS
C4
+++++ 603010019 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0603 X7R 3.03000 PCS
C5 C1 C3
+++++ 603010144 CAP CERAMIC SMD 0.022uf/50V +10%-10% 0603 1.01000 PCS
C2
++++ 6110200540 Slide Potentiometer
H3043N1-2 FC B10KA L5B(M)(J4)
Travel=30mm L=5mm HongYu
1.00000 PCS
VR3
+++ 1019903140 Accelerometer Board ASSY LQVL 1.00000 SET
++++ 6280103830 Masculine connector 8Pins/2.00mm 2*4 straight feet DIP 1.00000 PCS
J1
++++ 1019903150 Accelerometer Board ASSY LQVL 1.00000 SET
+++++ 603010019 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0603 X7R 2.00000 PCS
C1 C2
+++++ 603010257 CAP CERAMIC SMD 10uf/16V +10%-10% 0603 X5R Yageo 2.00000 PCS
C3 C4
+++++ 602010144 Resistor SMD 4.7K ohm(1/16w)+1%-1% 0603 2.00000 PCS
R1 R2
+++++ 6010111480 IC SMD
GMA302KU Ver:U0A Tri-axial digital
accelerometer with ±16g dynamic range DFN10
Tape and Reel GlobalMEMS
1.00000 PCS
U1
+++++ 506040552 PCB Dual layer FR4 1.6mm
LQVL_Accelerometer Board_V02 FR4 Pad with
HASL black silkscreen yellow gel
20.5*19*1.6mm
1.00000 PCS
+++ 628110021 cable tie with meson
outer Dia.9 inner Dia.φ4.0 T=0.5mm length 55+/-
5mm
1.00000 PCS

Alesis Vortex Wireless 2 Specifications

General

Product color	Black, White
Volume control	Touch
Knobs color	Black
Control type	Buttons, Sensor
Number of pads	8
Backlight color	Multicolor
Backlight buttons	Yes
MIDI-keyboard number of keys	37 keys
Interface	USB
Bundled software	Hybrid 3, Loom 2, Vacuum Pro & Xpand! 2 from AIR Music Tech, TimewARP 2600 from Way Out Ware & Ableton Live Lite
Battery type	AA
Number of batteries supported	4
Minimum RAM	4000 MB
Minimum processor	Dual Core 2GHz, Intel Core i5/i7
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 7
