18
Parts List
+++ 621030064 Film Switch
9091-0121-K MK46_FSR_Film
Sensor_V02_160108
1.00000 PCS
+++ 631020017 Black Velvet paper 66*30*0.3mm viscosity 2.00000 PCS
+++ 628060211 FFC Cable
18PIN L=50mm PH1.0mm two side with 5mm
stiffening plate conductor with 3mm
1.00000 PCS
+++ 628072056
Blue and White Flat Cable with
Cathode Plug in both sides
L=450mm UL2468 24AWG Both sides with
8pin/2.54 anti-drop cathode plug Cathode plug in
different sides
1.00000 PCS
+++ 628072057
Blue and White Flat Cable with
Cathode Plug
L=360mm UL2468 24AWG One side with
2PIN/2.0 anti-drop cathode plug Another side
with 4pin*2.54 Contact Pin
1.00000 PCS
+++ 628072058
Color Flat Cable with Cathode
Plug
UL1007 26AWG One side with 2pin/2.54 anti-
drop cathode plug L=80mm for Red L=300mm
for Black Another side strip and tin
1.00000 PCS
+++ 6280720610
Computer Flat Cable with
Cathode Plug
L=100mm UL2651 28AWG Both sides with
2*4PIN/2.0 cathode plug Cathode plug in
different sides
1.00000 PCS
+++ 6280720620
Computer Flat Cable with
Cathode Plug
L=300mm UL2651 28AWG Both sides with
2*4PIN/2.0 cathode plug Cathode plug in
different sides
1.00000 PCS
+++ 6280720630
Computer flat Cable with Cathode
Plug in both sides
L=380mm UL2651 28AWG Both sides with
2*10PIN/2.0 cathode plug Cathode plug in
different sides
1.00000 PCS
+++ 6280720640
Computer flat cable with cathode
plug in both sides
20pin L=280mm UL2651 28AWG Both with
2*10Pin/2.54mm cathode plug with butterfly style
buckle Plug in different sides
1.00000 PCS
+++ 1019903200 Wireless Transmitter Board ASSY LQVL 1.00000 SET
++++ 6280103830 Masculine connector 8Pins/2.00mm 2*4 straight feet DIP 1.00000 PCS
J1
++++ 1019903210
Wireless Transmitter Board
ASSY(SMD Part)
LQVL 1.00000 SET
+++++ 506070135 PCB Dual layer FR4 0.8mm
LQVL_TB_V02 FR4 Pad with ENIG Black
silkscreen Yellow Oil 30.75*30*0.8mm
1.00000 PCS
+++++ 603010268 Ceramic CAP SMD 1.5p/50V +/- 0.1pF 0402 NPO Yageo 1.00000 PCS
C6
+++++ 603010163 CAP CERAMIC SMD 1nf/50V +10%-10% 0402 1.00000 PCS
C2
+++++ 603010150 CAP CERAMIC SMD 0.01uf/50V +10%-10% 0402 SMD 1.00000 PCS
C1
+++++ 603010267 Ceramic CAP SMD 1P/50V +/- 0.1pF 0402 NPO Yageo 1.00000 PCS
C7
+++++ 603010270 Ceramic CAP SMD 20P/50V +/- 2% 0402 NPO Yageo 2.00000 PCS
C4-5
+++++ 603010261 CAP CERAMIC SMD 2.2nf/50V +5%-5% 0402 NPO Yageo 1.00000 PCS
C8
+++++ 603010271 CAP CERAMIC SMD 33NF(0.033uf)/50V +10%-10% 0402 X7R Yageo 1.00000 PCS
C3
+++++ 603010269 Ceramic CAP SMD 4.7P/50V +/- 0.25pF 0402 NPO Yageo 1.00000 PCS
C9
+++++ 603030026 CAP Tantalum SMD 47uf/6.3V+10%-10% A 3.2*1.6 1.00000 PCS
C10
+++++ 604010072 Inductor SMD 2.7nH±0.3nH 0402 HBLS1005-2N7S HONGYEX 1.00000 PCS
L3
+++++ 604010073 Inductor SMD 3.9nH±0.3nH 0402 HBLS1005-3N9S HONGYEX 1.00000 PCS
L1
+++++ 604010074 Inductor SMD 8.2nH±5% 0402 HBLS1005-8N2J HONGYEX 1.00000 PCS
L2
+++++ 6010111500 IC SMD Si24R1—P QFN20 Tape and Reel CSM 1.00000 PCS
U1
+++++ 602010732 Resistor SMD 22K ohm(1/16w)+1%-1% 0402 Yageo 1.00000 PCS
R1
+++++ 6100900300 Crystal SMD
C7M1600012AEDHF0-ME18 16M 3225 CL=12pf
+/-20ppm HongKongCystal
1.00000 PCS
X1
+++++ 602010645 Resistor SMD 0 ohm(1/16w)+1%-1% 0402 2.00000 PCS
L4 L5
+++ 101990316 Wheel LED Board ASSY LQVL 1.00000 SET
++++ 628072060
Color Flat Cable with Cathode
Plug
L=110mm UL1007 26AWG Red/Black one side
with 2pin/2.54 anti-drop cathode plug Another
sides strip and tin 3.5mm
1.00000 PCS
J1
++++ 101990317
Wheel LED Board ASSYSMD
Part
LQVL 1.00000 SET
+++++ 619010169 LED SMD
WEJT81BC-881-ZD Blue 0805 IV150-
250mcd
(
10mA
)
Yon
g
er
j
ia
2.00000 PCS
LED1 LED2
+++++ 602010566 Resistor SMD 33 ohm(1/8w) ±1% 0805 2.00000 PCS
R1 R2
+++++ 502010209 PCB Single layer 94V0 1.6mm
LQVL_Wheel LED Board_V02 94V0 Pad with
copper white silkscreen Green oil
49*14.5*1.6mm
1.00000 PCS
+++ 699000258 Touch Ribbon LQVL_Touch Ribbon_V02 126*18mm 1.00000 PCS
+++ 6281200790
Shield cable with cathode plug in
both sides
4P L=460mm 2P(28UL2725 high frequency
twisted-pair) 1P(black 24UL1007) 1P(sheild
cable
)
4Pin/2.0 YL19417062301A
1.00000 PCS
+++ 631010056 Dustproof mesh
47*10*0.3mm black with Double-sided adhesive
strips
2.00000 PCS
+++ 642020080 IO PC
T=0.8mm dieline:79.4*25.4mm black
background silkscreen white Transparent
window 3M
1.00000 PCS
