Parts List
+++ 642010589 LENS
Black ground T=0.8mm 43.9*35.4mm 3m double
sides adhesive tape
1.00000 PCS
+++ 301110010 screw BB 2.6*6BB black Zn plating “+” Dual teeth PWB 22.00000 PCS
for PCB
+++ 631040493 EVA PAD
EVA black 16*16*6mm with 3M Double-sided
adhesive strips
1.00000 PCS
+++ 631020154 Black Velveteen 41*6.0*0.5mm viscosity Black 1.00000 PCS
++ 1020504240 Bottom cabinet ASSY LQVL 1.00000 SET
+++ 202020057 Bottom cabinet HIPS injection black Spray black PU 1.00000 PCS
++++ 202010142 Bottom cabinet HIPS injection black P=Pantone black C N/A 1.00000 PCS
+++++ 298020001 Plastic HIPS 0.80958 Kg
+++ 320070005 peg
Fe ∮14*9.5mm plating Ni
2.00000 PCS
+++ 301230021 Screw
3*18KB Color Ni “+”Dual teeth flat tail
Self_tapping
2.00000 PCS
+++ 309070116 Battery spring +
∮0.8 spring wire plating Ni
1.00000 PCS
+++ 309070117 Battery spring -
∮0.8 spring wire plating Ni
1.00000 PCS
+++ 631040298 Force-rebounce Glue Black EVA 25*25mm T=1.0 with adhesive 2.00000 PCS
+++ 301110010 screw BB 2.6*6BB black Zn plating “+” Dual teeth PWB 26.00000 PCS
+++ 301110052 Screw BB 3*10mm BB plating Ni+Zn“+”slot 16.00000 PCS
+++ 101080178 Keyboard ASSY LQVL 1.00000 SET
++++ 628010084 Masculine connector
10PIN*2 straight feet DUAL ROW WITH BOX
HEADER
1.00000 PCS
J1
++++ 101080179
Keyboard ASSY（SMD Part）
LQVL 1.00000 SET
+++++ 608010031 Switch Dual Diode SMD BAW56A1 SOT-23 common anode 37.00000 PCS
D1-D37
+++++ 502020004 PCB Single layer 94V0 1.6mm
LQVL_KB_V02 94V0 Pad with Copper White
silkscreen Green Oil Carbon 513*62.6*1.6mm
1.00000 PCS
+++ 1011006380 Interface Board ASSY LQVL 1.00000 SET
++++ 628010231 Masculine connector
2Pins/2.54mm Pitch single line straight prevent
fall off
1.00000 PCS
JK1
++++ 628010291 Masculine connector
4Pins/2.00mm single line Straight foot Belt
buckle card
1.00000 PCS
J3
++++ 628010313 Mascoline connector
8Pins/2.54mm pitch single line straight prevent
fall off
1.00000 PCS
J1
++++ 60308001701 CAP ELECT DIP
1000uf/16V +20% -20% 10*16mm PIN length
3.5+/-0.3MM
1.00000 PCS
C1
++++ 605000002 Coil TC623-30UH*2-F-03 DIP 2.00000 PCS
L1-2
++++ 1010601350 Switch Board ASSY LQVL 1.00000 SET
+++++ 6210200370 Slide Switch
3 position slide switch HY-1305003 HSS23F07-
AT12-036 HONG YU
1.00000 PCS
SW1
+++++ 506040551 PCB Dual layer FR4 1.6mm
LQVL_Switch Board_V02 FR4 Pad with HASL
White silkscreen Green oil 30*17*1.6mm
1.00000 PCS
++++ 1011006390
Interface Board ASSY（SMD
Part）
LQVL 1.00000 SET
+++++ 608040002 Schotthy Diode SMD SS24 2A 40V 1.00500 PCS
D2
+++++ 608030002 Rectifier Diode SMD IN4001 6.00*3.00mm 1.00500 PCS
D1
+++++ 603010019 CAP CERAMIC SMD 0.1uf/50V +10% -10% 0603 X7R 5.05000 PCS
C5 C9 C11 C2 C12
+++++ 6060100200 Ferrite Bead SMD BLM18BD102SN1D 1000ohm 0.1A 0603 3.03000 PCS
L5-7
+++++ 6049900040 Common mode inductor
280mA COMMON MODE 0805 ROHS“MURATA
”DLW21HN121SQ2 SMD
1.01000 PCS
L3
+++++ 602010393 Resistor SMD 10K ohm(1/10w)+1%-1% 0603 2.02000 PCS
R5 R10
+++++ 602010432 Resistor SMD 27 ohm(1/16w)+1%-1% 0603 2.02000 PCS
R2-3
+++++ 602010144 Resistor SMD 4.7K ohm(1/16w)+1%-1% 0603 2.02000 PCS
R8 R11
+++++ 602010135 Resistor SMD 47 ohm(1/8w)+5%-5% 0603 1.01000 PCS
R1
+++++ 602010205 Resistor SMD 68 ohm(1/8w)+5%-5% 0603 2.02000 PCS
R6-7
+++++ 609010074 Transistor SMD SS8050 NPN SOT-23 1.00500 PCS
Q2
+++++ 609010053 Transistor SMD MMBT8550D(1500mA) PNP SOT-23 1.00500 PCS
Q1
+++++ 506040550 PCB Dual layer FR4 1.6mm
LQVL_IOB_V02 FR4 Pad with HASL black oil
White Silkscreen 97*40*1.6mm
1.00000 PCS
+++++ 602010025 Resistor SMD 1M ohm(1/8w)+5%-5% 0603 1.00000 PCS
R4
++++ 620030003 MIDI JACK 7PIN DIN-01R-M10 DIP 1.00000 PCS
J4
++++ 620050016 USB Jack 6PIN P=2.0mm Plug force 15N~30N 1.00000 PCS
J2
++++ 60308010001 CAP ELECT DIP
100uf/16V +20%-20% 5*7mm DIP PIN length
3.5+/-0.3MM
1.00000 PCS
C8
+++ 209020022 Battery door(big) HIPS injection black spray Black+PU 1.00000 PCS
++++ 209010036 Battery cover (big) HIPS injection black P=Pantone black C N/A 1.00000 PCS
+++++ 298020001 Plastic HIPS 0.03200 Kg
+++ 209020023 Battery door(small) HIPS injection black spray Black+PU 1.00000 PCS
++++ 209010037 Battery cover (small) HIPS injection black P=Pantone black C N/A 1.00000 PCS
+++++ 298020001 Plastic HIPS 0.02472 Kg
+++ 628110021 cable tie with meson
outer Dia.9 inner Dia.φ4.0 T=0.5mm length 55+/-
5mm
3.00000 PCS
+++ 631020017 Black Velvet paper 66*30*0.3mm viscosity 3.00000 PCS
To Next Page
