Alesis Vortex Wireless 2 Service Manual

20
Parts List
+++ 204010021 Black key ABS injection black N/A 3.00000 PCS
++++ 298010001 Plastic ABS 0.05562 Kg
++++ 298050010 Color seed M5735C 70%ABS250+30%AS 0.5kg 1.19360 g
+++ 205010115 Single white key ABS White N/A 1.00000 PCS
++++ 298010001 Plastic ABS 0.01648 Kg
++++ 298050016 Color seed A61 YS-87527-SM (The ratio 8%) 1.30000 g
+++ 205010113 White key(3key group) ABS White N/A 3.00000 PCS
++++ 298010001 Plastic ABS 0.04223 Kg
++++ 298050016 Color seed A61 YS-87527-SM (The ratio 8%) 3.60000 g
+++ 205010114 White key(4key group) ABS White N/A 3.00000 PCS
++++ 298010001 Plastic ABS 0.05253 Kg
++++ 298050016 Color seed A61 YS-87527-SM (The ratio 8%) 4.56000 g
+++ 631030310 Bottom limit felt
530*13*2.0mm white single side with glue the
hardness of 60 degrees
1.00000 PCS
+++ 631030311 Key hook felt
520*6*2.5mm black felt single side with general
glue the hardness of 55 degrees
1.00000 PCS
+++ 629990396 Rubber strip
515*8*4.2mm Silicone+Polyfoam black single
side with 3M glue the hardness of 45 degrees
1.00000 PCS
+++ 629010068 Conductive Rubber
Painting carbon blue long life siticagel the
hardness of 40 degrees 177.5*22.8*16.2mm
3.00000 PCS
+++ 301070016 screw PWB 3*20PWB Color Zn crisscross PWB 13.00000 PCS
+++ 628990076 After touch bar LQVL-37AfterTouch_Strip_V01 9091-0135-K 1.00000 PCS
+++ 631040491 EVA pad
EVA black 29*23*6mm with Double-sided
adhesive strips on top ＆ bottom sides
1.00000 PCS
++ 1029901720 Wireless Receiver module ASSY. LQVL 1.00000 SET
+++ 216030015 USB top cover
ABS injection black spray black silkscreen White
LOGO PU
1.00000 PCS
++++ 216010123 USB top cover ABS injection black N/A 51*22.5*5.35mm 1.00000 PCS
+++++ 298010001 Plastic ABS 0.00206 Kg
+++ 216030016 USB bottom cover
ABS injection black spray black silkscreen White
CE PU
1.00000 PCS
++++ 216010122 USB bottom cover ABS injection black N/A 51*22.5*5.35mm 1.00000 PCS
+++++ 298010001 Plastic ABS 0.00206 Kg
+++ 101990318002 Wireless Receiver Board ASSY LQVL 1.00000 SET
++++ 101990319002
Wireless Receiver Board ASSY
（SMD Part）
LQVL 1.00000 SET
+++++ 506070136 PCB Dual layer FR4 0.8mm
LQVL-RB-V02 FR4 Pad with ENIG Black
silkscreen Yellow oil 47*18.6*0.8mm
1.00000 PCS
+++++ 603010231 CAP CERAMIC SMD 0.1uf/50V +10%-10% 0402 X7R 7.00000 PCS
C1-5 C48 C78
+++++ 603010268 Ceramic CAP SMD 1.5p/50V +/- 0.1pF 0402 NPO Yageo 1.00000 PCS
C12
+++++ 603010163 CAP CERAMIC SMD 1nf/50V +10%-10% 0402 1.00000 PCS
C8
+++++ 603010233 CAP CERAMIC SMD 1uF/25V ±10% X5R 0402 SMD 2.00000 PCS
C16 C17
+++++ 603010150 CAP CERAMIC SMD 0.01uf/50V +10%-10% 0402 SMD 2.00000 PCS
C6-7
+++++ 603010267 Ceramic CAP SMD 1P/50V +/- 0.1pF 0402 NPO Yageo 1.00000 PCS
C13
+++++ 603010261 CAP CERAMIC SMD 2.2nf/50V +5%-5% 0402 NPO Yageo 1.00000 PCS
C14
+++++ 603010270 Ceramic CAP SMD 20P/50V +/- 2% 0402 NPO Yageo 2.00000 PCS
C10-11
+++++ 603010271 CAP CERAMIC SMD 33NF(0.033uf)/50V +10%-10% 0402 X7R Yageo 1.00000 PCS
C9
+++++ 603010269 Ceramic CAP SMD 4.7P/50V +/- 0.25pF 0402 NPO Yageo 1.00000 PCS
C15
+++++ 603010243 CAP CERAMIC SMD 22uF/25V +20% -20% 0805 X5R SMD 1.00000 PCS
C19
+++++ 604010072 Inductor SMD 2.7nH±0.3nH 0402 HBLS1005-2N7S HONGYEX 1.00000 PCS
L4
+++++ 604010073 Inductor SMD 3.9nH±0.3nH 0402 HBLS1005-3N9S HONGYEX 1.00000 PCS
L1
+++++ 604010074 Inductor SMD 8.2nH±5% 0402 HBLS1005-8N2J HONGYEX 1.00000 PCS
L3
+++++ 606010035 Ferrite Bead SMD BLM18PG471SN1D 1A 0603 murata 2.00000 PCS
L5-6
+++++ 602010645 Resistor SMD 0 ohm(1/16w)+1%-1% 0402 1.00000 PCS
L2
+++++ 602010719 Resistor SMD 1.5K ohm(1/16w)-1%+1% 0402 Yageo 1.00000 PCS
R1
+++++ 602010644 Resistor SMD 100 ohm(1/16w)+1%-1% 0402 2.00000 PCS
R6-7
+++++ 602010640 Resistor SMD 10K ohm(1/16w)+1%-1% 0402 2.00000 PCS
R2-3
+++++ 602010732 Resistor SMD 22K ohm(1/16w)+1%-1% 0402 Yageo 1.00000 PCS
R5
+++++ 602010763 Resistor SMD 27 ohm(1/16w)+1%-1% 0402 Yageo 2.00000 PCS
R16-17
+++++ 602010731 Resistor SMD 1M ohm(1/16w)+1%-1% 0402 Yageo 1.00000 PCS
R28
+++++ 6100900300 Crystal SMD
C7M1600012AEDHF0-ME18 16M 3225 CL=12pf
+/-20ppm HongKongCystal
1.00000 PCS
X1
+++++ 6010111600 IC SMD
SGM803-TXN3L/TR RESET
THRESHOLD:3.08V Open-Drain RESET Output
Reset time(type):240ms SOT-23 SGMICRO
1.00000 PCS
U15
+++++ 6010109340 IC SMD
STM32F103C8T6 LQFP48 Flash Memory 64Kb
SRAM Memory 20Kb ST
1.00000 PCS
U3

Alesis Vortex Wireless 2 Specifications

General

Product color	Black, White
Volume control	Touch
Knobs color	Black
Control type	Buttons, Sensor
Number of pads	8
Backlight color	Multicolor
Backlight buttons	Yes
MIDI-keyboard number of keys	37 keys
Interface	USB
Bundled software	Hybrid 3, Loom 2, Vacuum Pro & Xpand! 2 from AIR Music Tech, TimewARP 2600 from Way Out Ware & Ableton Live Lite
Battery type	AA
Number of batteries supported	4
Minimum RAM	4000 MB
Minimum processor	Dual Core 2GHz, Intel Core i5/i7
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 7
