Alesis Vortex Wireless 2 Service Manual

Parts List
21
+++++ 6010108260 IC SMD AP7313-33SRG-7 Diodes Inc 1.00000 PCS
U2
+++++ 6010111500 IC SMD Si24R1—P QFN20 Tape and Reel CSM 1.00000 PCS
U1
+++++ 606010042 Ferrite Bead SMD
121 OHM@100MHz 0402 200mA
EBMS100505A121 HongYEX
3.00000 PCS
L7-8 L11
+++++ 602010642 Resistor SMD 100K ohm(1/16w)+1%-1% 0402 1.01000 PCS
R20
++++ 6200500280 USB JACK UZ-USB20-4450-01A Yilong 1.00000 PCS
USB-AM
+ 1020206840 Outer packing materials LQVL 1.00000 SET
++ 634000455 EPE Left top EPE black 375*300*75mm 1.00000 PCS
++ 634000457 EPE Left bottom EPE black 375*300*75mm 1.00000 PCS
++ 634000456 EPE right EPE black 300*125*100mm 1.00000 PCS
++ 649003785 Accessory box
250g pink gray A3 strengthen core die
cut:556*365mm white box
1.00000 PCS
++ 649003786 Outer carton A=B dieline:968*344*323mm 0.33333 PCS
++ 699000261 Non-woven Fabrics bag
976*312mm 0.5mm Non-woven Fabrics sewing
bag
1.00000 PCS
++ 643010179 Bone closure Polybag PE 230*340*0.03mm printing warning 1.00000 PCS
++ 699000252 strap
1380mm*50mm black Nylon fabrics+ plastic
fastener+PU+string
1.00000 PCS
++ 699000253 Harness Nylon fabrics black 140*20*1.2mm 1.00000 PCS
++ 641011153 Label
English bright white PET white word on black
size:81*40mm 4-R1
1.00000 PCS
++ 639002562 Manual Multilanguage 140*216mm 100g/60g “ALESIS” 1.00000 PCS
++ 647000790 Gift box
300g pink gray+A3 strengthen(120g)
dieline:940*305*107mm 4C+UV
1.00000 PCS
++ 641070365 Code39 bar code Black word on white 90*42mm 1.00000 PCS
++ 641040128 Serial number Label Black word on white bright white PET 70*15mm 3.00000 PCS
++ 6280800120 USB cable
L=2000mm±50 PVC Black magnet ring one
side USB “A” type The other end USB“B” type
1.00000 PCS
++ 643010069 Bone closure Polybag PE 80*60*0.03mm no printing 1.00000 PCS
++ 641070374 ITF-14 bar code Black word on white 90*42mm 0.66660 PCS
++ 640000414 Safety and warranty manual Five language 100g/60g 5.5*8.5inch ALESIS 1.00000 PCS
++ 640000304 Ableton paper card
Size: 120*120 mm the material is 400g of copper
plate the bottom of the light to half light Black
printing.
1.00000 PCS
++ 641990495 Ableton Live Lite 9 code sticker
Black word on white size:65*7mm English the
factory print
1.00000 PCS
++ 640000444 Software download card
120*120mm the material is 400g of copper plate
the bottom of the light to half light Black
printing.REV C
1.00000 PCS
++ 641040133 USB SN Label 20*10mm white word on black 1.00000 PCS
++ 628110044 INSULOK CALBLE TIES INSULOK 120mm 1.00000 PCS

Alesis Vortex Wireless 2 Specifications

General

Product color	Black, White
Volume control	Touch
Knobs color	Black
Control type	Buttons, Sensor
Number of pads	8
Backlight color	Multicolor
Backlight buttons	Yes
MIDI-keyboard number of keys	37 keys
Interface	USB
Bundled software	Hybrid 3, Loom 2, Vacuum Pro & Xpand! 2 from AIR Music Tech, TimewARP 2600 from Way Out Ware & Ableton Live Lite
Battery type	AA
Number of batteries supported	4
Minimum RAM	4000 MB
Minimum processor	Dual Core 2GHz, Intel Core i5/i7
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 7
