Drawing/Parts list
Parts list
SRC DN125-150 - stop valve
Item Qty. Denomination
1 1 Cap
2¨ 2 O-ring
3 1 Cylinder
4¨ 1 Lock wire
5¨ 1 O-ring
6 1 Piston
7¨ 1 O-ring
8 1 Bonnet
9 2 Plug
10 1 Spring packet standard (black)
1 Extra strong spring alternative
(white)
14D 1 Lip seal
15 1 Clamp complete (stop valve)
2 Clamp complete (change-over
valve)
17D 1 Valve body seal ring
18 1 Valve body, lower
19 1 Valve plug, single, complete
19a 1 Stem
19eD 1 Seal ring
19f 1 Washer
19gD1 O-ring
19h 1 Screw
21¨ 1 Guide ring
22¨ 1 Guide ring
23 1 Top pin
24¨ 1 O-ring
25¨ 1 Guide ring
27¨ 1 Guide ring
D : Service kit - EPDM, NBR, FPM
(See Spare Parts List)
¨ : Only for NO - and NC actuators.
The drawings and the parts list include all items.
NO = Normally open.
NC = Normally closed.
The items are identical with the items in the Spare Parts
List.
When ordering spare parts, please use the Spare Parts
List!
