Drawing/Parts list
The drawings and the parts list include all items.
NO = Normally open.
NC = Normally closed.
The items are identical with the items in the Spare Parts
List.
When ordering spare parts, please use the Spare Parts
List!
Parts list
SRC - change-over valve 25 mm
Pos. Qty. Denomination
1 1 Cap
2D 2 O-ring
3 1 Cylinder
4D 1 Lock Wire
5D 1 O-ring
6 1 Piston -1, -2
1 Piston -3
7D 1 O-ring
8 1 Bonnet
9* 2 Plug
10* 1 Spring assembly (standard black)
11D 1 Clip, complete
14D 1 Lip seal
15a+b 1 Clamps and screws
16 1 Upper valve body
17D 1 Valve body seal ring
18 1 Lower valve body
20 1 Plug, double, complete
20b 1 Stem
20cD ● 1 Upper seal ring
20d 1 Middle piece
20eD ● 1 Lower seal ring
20f 1 Screw
D : Service kit - EPDM, NBR, FPM
(See Spare Parts List)
●: Service kits special lip seals.
(See Spare Parts List)
* : Only for NO - and NC actuators.
To Next Page
