Terminals V70 Digital-IO 24V
1 Power supply 24V (brown)
2 Power supply GND (blue)
3 out Status OK (white)
4 out Valve de-energised (DE-EN) (black)
5 out Main valve energised (EN) (grey)
6 out Upper seat lift energised (USL) (pink)
7 out Lower seat push energised (LSP)
8 in Solenoid valve 1 for main valve (SV1)
9 in Solenoid valve 2 for USL (SV2)
10 in Solenoid valve 3 for LSP (SV3)
1 Seat lift sensor Supply (brown)
2 Seat lift sensor GND (blue)
3 Seat lift sensor Signal (black)
M12 plug option wiring overview (8-pin A-coded plug)
Factory wiring overview for each solenoid valve configuration
Control board
1x3/2 2x3/2 3x3/2 1x5/2
Terminal reference
1 24V Brown (pin 1) Brown (pin 1) Brown (pin 1) Brown (pin 1)
2 GND Blue (pin 3) Blue (pin 3) Blue (pin 3) Blue (pin 3)
3 out: Status White (pin 2) White (pin 2) White (pin 2) White (pin 2)
4 out: DE-EN Black (pin 4) Black (pin 4) Black (pin 4) Black (pin 4)
5 out: EN, Main valve Grey (pin 5) Grey (pin 5) Grey (pin 5) Grey (pin 5)
6 out: USL, Upper seat Pink (pin 6) - - Pink (pin 6)
7 out: LSP
, Lower seat Violet (pin 7) Violet (pin 7) - Violet (pin 7)
8 in: SV1, Main valve Orange (pin 8) Orange (pin 8) Orange (pin 8) Orange (pin 8)
9 in: SV2, Upper seat - Pink (pin 6) Pink (pin 6) -
10 in: SV3, Lower seat - - Violet (pin 7) -
200000549-1-EN-GB 13
