Alfa Laval ThinkTop - Installation on Series 700 Valves

5Installation
5.2InstallationonSeries700valves
Step Step
Step
1 1
1
1.Removethecoverbylooseningthefourcoverscrews.
2.Separatetheadapterfromthebasebylooseningthethree
recessscrewsontopofthebase.
Installationonairactuators:
Step Step
Step
2 2
2
1.Fitairfittingsonactuator.
2.Positionpackingretainerinrecessonactuatortop.
3.Fitcounternutandindicationpin(magnet)onactuatorrod.
Engageapprox.¼thread.Tightencounternutandindicator
withtwowrenches.
Step Step
Step
3 3
3
1.PlacethetwoO-ringsinthegroovesinthebottomofthe
adapter.Thenplacetheadapterontheactuatortop.Thesmall
O-ringmustbepositionedovertheairholeontheactuator.
2.Fastentheadapterwiththefour5/16”Allenscrews.
19
