8Maintenance

Readtheinstructionscarefully.

Handlescrapcorrectly.

AlwayshavespareX-ringstohand.

8.1DismantlingThinkTop

Step Step

Step

1 1

1.UntightenthetwoAllenscrewsandremovetheThinkTopfrom

theactuator

2.PulloutX-ring(19)andreplaceit

Step Step

Step

2 2

1.Untightenthefourscrews

2.RemoveThinkTopcover

3.RemoveX-ring(9)(grey)

Step Step

Step

3 3

1.Untightenscrews

2.Removesolenoidvalves(uptothree)andreplacethemwith

newones

Step Step

Step

4 4

1.Todismantletheadapter(thelowerpartoftheThinkTop)from

base(themiddlepart),unscrewthethreescrews

2.Turnthelowerpartclockwiseslightlyandpull

3.Replaceadapterifnecessary

4.RemovetheblackX-ring

Note: Note:

Note:

Turnbanjoconnection!
