Alfa Laval ThinkTop - Assembly of ThinkTop

8Maintenance
Readtheinstructionscarefully.
Handlescrapcorrectly.
AlwayshavespareX-ringstohand.
Step Step
Step
5 5
5
Toremovethesensorunit,untightenscrewandpullout
thesensorunit.
8.2AssemblyofThinkTop
Step Step
Step
1 1
1
Placesensorunitinbaseandtightenscrew(torque:1Nm).
Step Step
Step
2 2
2
1.ReplacetheblackX-ring.
2.Assemblebasewithadapterbyturningadapterslightly
anticlockwiseandtightenthefourscrews(1.9Nm).
CAUTION! CAUTION!
CAUTION!
DoNOTtwisttheX-ringinthegroove!
TheX-ringisnotsquare.Thehighest(h)part
mustbepositionedasshown.
Note: Note:
Note:
Turnbanjo
connection!
35
