8Maintenance
Readtheinstructionscarefully.
Handlescrapcorrectly.
AlwayshavespareX-ringstohand.
Step Step
Step
4 4
4
1.Mountthebaseontheadapterinthenecessaryposition(can
berotated120°inbothdirections).Notethatoneofthescrew
towersontheadapterhasaguiderecess(see*ondrawing).
2.RemoveX-rings(9)(grey)and(16)(black).
3.Replacewithnewones.
CAUTION! CAUTION!
CAUTION!
DoNOTtwisttheX-ringinthegroove!TheX-ringis
notsquare;Thehighest(h)partmustbepositionedasshown
