62 | Operating the monitor
Using the tilt, swivel, and vertical extension
NOTE: The following instructions are applicable only for attaching the
stand that was shipped with your monitor. If you are attaching a stand
that you purchased from any other source, follow the setup instructions
that were included with the stand.
Tilt and swivel extensions
With the stand attached to the monitor, you can tilt and swivel the monitor for
t
he most comfortable viewing angle.
NOTE: The stand is not factory-installed.
NOTE: The slant angle of this monitor is between -5° and +5°, not
allowing for pivot movements.
Vertical extension
NOTE: The stand extends vertically up to 110 mm. The following figure
illustrates how to extend the stand vertically.
