7. Heat sink
8. Right-I/O board
9. Battery
10.Left speaker
11. Palm-rest and keyboard assembly
12. Display assembly
13. Touchpad
14. Touchpad bracket
15.Keyboard-controller board
16.Right speaker
17. Rear-I/O cover
18.Left-I/O board
19.Power button
20.Power-button bracket
21. Right fan
22.Memory modules
23.Wireless card
24.Wireless-card bracket
25.System board
26.Type-C bracket
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These parts
are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for purchase
options.
Disassembly and reassembly
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Base cover
Removing the base cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
The following image(s) indicate the location of the base cover and provides a visual representation of the removal procedure.
12
