DUALBANDER
*General
Frequency
Coverage . . . . . . . . . . . . . . . . . .
144.00-147.995Mhz.
&
440-4450Mhz(U.S.Version)
Frequency
Resolution . . . . . . . . . . . . . . . . . .
144:00-145.9875Mhz.
8
430-440Mhz(Europe
Version)
5, 10, 12.5, 15, 20 and 25Khz. steps
Antenna Impedance
.....................
50 ohms unbalanced
Power Supply requirement
............
13.8 Volts D.C.
Current Drain at
13.8V
..................
Receiving
Dimension
.................................
Weight
.......................................
@Transmitter
Output
power
..............................
Emission
Mode
...........................
Modulation
System
.....................
Max.
Frequency Deviation
............
Spurious
Emission
.....................
Microphone
..............................
Operating
Mode
........................
DTMF
Encoder
............................
@Receiver
Receiving
System
........................
Modulation acceptance
...............
Intermediate frequency
...............
Sensitivity
..................................
Selectivity
.................................
Squelched
:
does not exceed 500mA
Transmitting
High:45W approx. 9.5A at VHF
High:35W approx. IOA at UHF
Low: 5W approx.4A at VHF
Low: 5W approx.4A at UHF
14Omm(W)
x 50mm(H) x 205mm(D)
(5--1/2”)~(2”)~(8-l/16”)
Approx.
1.7Kgs.(3.75Lbs.)
High:45Watts at
VHFJBWatts
at-
Low:Approx.
5Watt.s
at both bands
18F3
Variable Reactance F.M.
f5Khz
More than 80dB below Carrier
Electret Condenser Microphone
Simplex
Duplex:
k
6OOKhz
from receive frequency
at
144--147.995Mhz
or
144-145.9875Mhz
fl.6,
5 and 7.6Mhz from receive
friquency.
at
440.00-4450.00Mhz.
or 430-440Mhz
Built-in
Superhetrodyne, dual conversion
16F3
1st 10.7Mhz 2nd 455Khz at VHF
1st
30.825Mhz
2nd 455Khz at UHF
12dB
SINAD less than
O.l6@V
More than
+8Khz
at -6dB
Less than
+lPKhz
at
-8OdB
Audio
power
Output
.....................
More than
15Watts(8ohms-10%
Distortion)
Speaker Impedance
.....................
8 ohms
Note:Specifications are subject to change without notice.
Specifications are guaranteed for amateur band only.
.
n Front Panel
OMain
Dial
@LCD Panel
@Volume Control
0
Squelch Control
0
H/L Switch
@Power Switch
@Function/Memory Write Key
@
MHz(Band) Key
@VFO/M/Channel
Step Key
@I
Reverse/Lock Key
@Shift
Key
@Sub Tone/Beep Key
@I
Priority Key
@Scan/Memory Skip Key
.@Call Channel/Call Channel Write Key
(DR-5lOE
:
Tone Burst Key)
@Microphone Terminal
@
Reverse Indication
@Offset Indication
@Tone Encoder Indication
@Tone Decoder(Tone Squelch)lndication
@Priority Indication
@Call Channel Indication
@
Frequency Indication
@Decimal Readout Point
@t
Busy Indication
@S/RF
Meter Indication
@On
Air Indication
@Memory Indication
@Memory Channel Indication
ry
Wtugged
Die-Cast Chassis
--
