ALKOTA 4142 - Page 43

FILFIL
FILFIL
FIL
TER,TER,
TER,TER,
TER,
FUEL FUEL
FUEL FUEL
FUEL
P/N V04-00308
REMEDY
1. Fuel bowl leaking.
2. Air leaking into system
(indicated by air bubbles in bowl
during operation).
A. Deteriorated gasket.
B. Housing Cracked.
C. Bowl rim cracked, nicked, or scratched.
D. Gasket missing.
E. Loose Fuel Bowl.
A.Loose Valve Assembly.
B. craked Component.
C. loose Filter bowl.
A. Remove and Replace Gasket.
B. Remove and Replace Housing.
C. Remove and Replace Bowl.
D. Replace Gasket.
E. Tighten Fuel Bowl Onto Filter.
A.Tighten Valve Assembly.
B. Inspect Filter Bowl, Filter Housing,
and Gasket.
C. Tighten Fuel Bowl Onto Fuel Filter.
TROUBLE
POSSIBLE CAUSE
TRTR
TRTR
TR
OUBLE SHOOOUBLE SHOO
OUBLE SHOOOUBLE SHOO
OUBLE SHOO
TINGTING
TINGTING
TING
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• MAXIMUM FLOW 15 GPH / 57 LPM
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• MAXIMUM FILTRATION 2 MICRONS
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• MAXIMUM TEMPERATURE 212°F / 100°C
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• WEIGHT 1.0 LBS. / 340 GM
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• INLET 1/4 NPT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• OUTLET 1/4 NPT
SPECIFICASPECIFICA
SPECIFICASPECIFICA
SPECIFICA
TIONSTIONS
TIONSTIONS
TIONS
09-01-04 Z08-01792
Supersedes 05-25-01 Z08-01792
3 1/4"
5 1/2"
(6 1/2" Required For
Element Removal)
Inlet
Vent Plug
Drain Port
Outlet
ALL DIMENTIONS ARE
IN INCHES UNLESS OTHERWISE
NOTED. 25.4 MM = 1 INCH
