ALL-TEST PRO AT31 - Testing Phase T2-T3

ALL-TEST PRO
®
31 User Manual
©2011, ALL-TEST Pro, LLC www.alltestpro.com rev 2011-11F 15
4. Record these test results on the Motor Test Form.
Continue with Last Phase
1. Move the Test Leads to T2 & T3
ALL-TEST Pro® 31 Motor Test Form
Motor ID:
Location:
Test Date:
Test Frequency
Phase
1-2
Phase
1-3
Phase
2-3
Impedance (Z)
107 107
Phase Angle (°)
66 66
Z-Test or I/F
-45 -45
Phase balance (opt)
Ins Resistance
Test
Voltage
Was rotor set to lowest value during phase balance test? Y__ N__
Rotor test performed? Y___ N___
Comments:
