ALLEN & HEATH CQ-18T User Manual

 57
User Guide V1.1.0 Issue 1
Store Processing Parameters Using Libraries
1.
Go to PROCESSING, locate the bank of faders from
the top of the screen containing the channel with
processing to be stored.
2.
Select the channel, then stay in bank view to store
a whole channel or select a processing block (e.g.
PEQ) to view in detail and store only that part of
the processing.
3.
Open the Library from the top right-hand corner of
the screen. A different library will open depending
on the screen currently being viewed.
4.
Select Store new to store all settings from the
selected channel/processing block.
5.
Switch to the User library to manage User
Libraries.
6.
Select an existing item in the list and use
Overwrite to store settings for the selected
channel/processing block over the top of an
existing item.

ALLEN & HEATH CQ-18T Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	18 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Output impedance	75 Ω
Built-in display	Yes
Compatible memory cards	SD, SDHC
Master (XLR) out	2
Number of microphone inputs	18
Video capability	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	346 mm
Height	89 mm
Weight	3000 g
Package depth	310 mm
Package width	430 mm
Package height	200 mm
Package weight	3800 g
