ALLEN & HEATH XONE:96 User Manual

ALLEN&HEATH 36 AP11645_1_XONE:96 User Guide
SPECIFICATIONS continued
Model XONE:96
Type Analogue
Channels 6 + 2
EQ 4-Band: CH 1- 4 ¦ 3-Band, Parametric: CH A/CH B
BOOTH 3-Band EQ ¦ STERO/MONO ¦ MUTE ¦ Level
USB Soundcards USB1 / USB2 2 x 24 Channel ¦ 12 in / 12 out [6 x Stereo pairs]
Hi-Speed USB2.0 [USB B] ¦ macOS Class Compliant [see p.24]
32bit / 96kHz
2 x MIDI IN
2 x MIDI Out
USB Inputs 2 x 6: [CH 1- 4 ¦ SEND1 ¦ MST/SEND2]
USB Outputs 2 x 6: USB1 / USB2 [CH 1- 4 ¦ CH A - D]
Phono Inputs 4 x RCA: CH 1- 4
LN/PH Switch for DVS
Earth Ground Terminals x 2
Line Inputs 4 x RCA [CH 1- 4]
4 x 1/4" TRS [RTN A - D] Mono/Stereo
Mic Input 2 x XLR [MIC A / MIC B]
MST 1 Output 1 x XLR [Balanced]
MASTER INSERT 2 x 1/4" TRS [Balanced SEND / Un-balanced RETURN]
MST 2 Output 1 x 1/4" TRS [Balanced]
BOOTH Output 1 x 1/4" TRS [Balanced]
RECORD Output 1 x RCA [Un-balanced]
Send/Return I/O 2 x 1/4" TRS [SND1 / SND2] Mono/Stereo
4 x 1/4" TRS [RTN A - D] Mono/Stereo
1 x LN/Hi-Z Switch [SND 1 / RTN A]
Aux Sends 2 x CH 1- 4 + CH A, CH B [SEND1 selectable Pre/Post]
X-Link 1 x RJ45 Ethernet
Filters 2 x Stereo analogue Voltage Controlled Filters
HPF / BPF / LPF Response Select ¦ ON/OFF [soft switched]
Adjustable FREQ / RES / CRUNCH [Controlled Harmonic Signal Distortion]
Assignable CH 1- 4, CH A, CH B
Channel Faders 60mm linear Voltage Controlled Amplifier [CH1 - 4, user replaceable]
Chanel Meters 9 Segment LED
Channel Fader Curve 3 Types
X-Fader innoFADER MINI standard ¦ 45mm linear VCA [user replaceable]
X-Fader Curve Settings 3 Types
MIDI Assignable Yes: MIDI CC ¦ MIDI Note ON/OFF
MIDI Out USB 1 / USB2 ¦ 1 x 5-pin DIN ¦ X:Link
MIDI In USB 1 / USB2 [CUE ¦ ON/OFF ¦ MUTE]
Power Supply Internal switch mode power unit [SMPS] with auto sensing mains input
AC Mains 100 to 240V AC ¦ 50/60Hz
Consumption 45W max
Rear panel mounted ON/OFF switch
Mains Adaptor 3 pin IEC socket with cable clamp. Molded AC plug [supplied]

ALLEN & HEATH XONE:96 Specifications

General

Channels quantity	8 channels
Digital sound processing	- bit
Equalizer bands quantity	4
DJ mixer	-
Product color	Black, Grey
USB connector type	USB Type-B
Master (XLR) out	1
Headphone connectivity	3.5 mm/6.35 mm
Number of microphone inputs	2
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	45 W
Built-in display	No

Weight and Dimensions

Depth	410 mm
Width	336 mm
Height	109 mm
Weight	7000 g
