ALLEN & HEATH XONE:96 User Manual

ALLEN&HEATH 27 AP11645_1_XONE:96 User Guide
MIDI CONTROL
MIDI stands for Musical Instrument Digital Interface; a protocol established in the 1980s to enable different
keyboards, sequencers, drum machines, etc. to communicate with each other.
MIDI remains a common and popular means to enable remote control of functions within DJ performance, or
DAW (Digital Audio Workstation) software.
XONE:96 has the ability to send and receive MIDI data, with a total of 31 MIDI enabled controls; 19 buttons, 5
faders and 7 rotary switches that can be assigned as controls for most Digital DJ and DAW applications.
Refer to the following colour coded image and tables for details of the MIDI controls, assignment values, and to
convert between equivalent hexadecimal, decimal and chromatic scale values.

ALLEN & HEATH XONE:96 Specifications

General

Channels quantity	8 channels
Digital sound processing	- bit
Equalizer bands quantity	4
DJ mixer	-
Product color	Black, Grey
USB connector type	USB Type-B
Master (XLR) out	1
Headphone connectivity	3.5 mm/6.35 mm
Number of microphone inputs	2
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	45 W
Built-in display	No

Weight and Dimensions

Depth	410 mm
Width	336 mm
Height	109 mm
Weight	7000 g
