DUAL INTERNAL SOUNDCARD, USB 1 - USB 2
USB AUDIO ROUTING
Mixer Channel outputs to Computer [USB1 and USB2]
Soundcard Input XONE:96 Outputs DAW Input
USB 1 / USB 2_1 CH1 L (RIAA or LINE) Ch 1 L
USB 1 / USB 2_2 CH1 R (RIAA or LINE) Ch 1 R
USB 1 / USB 2_3 CH2 L (RIAA or LINE) Ch 2 L
USB 1 / USB 2_4 CH2 R (RIAA or LINE) Ch 2 R
USB 1 / USB 2_5 CH3 L (RIAA or LINE) Ch 3 L
USB 1 / USB 2_6 CH3 R (RIAA or LINE) Ch 3 R
USB 1 / USB 2_7 CH4 L (RIAA or LINE) Ch 4 L
USB 1 / USB 2_8 CH4 R (RIAA or LINE) Ch 4 R
USB 1 / USB 2_9 SEND 1 L (PRE or POST) Send 1 L
USB 1 / USB 2_10 SEND 1 R (PRE or POST) Send 1 R
USB 1 / USB 2_11 SEND 2 L or MST L Send 2 L / MST L
USB 1 / USB 2_12 SEND 2 R or MST R Send 2 R / MST R
Mixer Channel inputs from Computer [USB1 or USB2]
Soundcard Output XONE:96 Inputs DAW Output
USB 1 / USB 2_1 CH 1 USB 1 or USB 2_L Ch 1 L
USB 1 / USB 2_2 CH 1 USB 1 or USB 2_R Ch 1 R
USB 1 / USB 2_3 CH 2 USB 1 or USB 2_L Ch 2 L
USB 1 / USB 2_4 CH 2 USB 1 or USB 2_R Ch 2 R
USB 1 / USB 2_5 CH 3 USB 1 or USB 2_L Ch 3 L
USB 1 / USB 2_6 CH 3 USB 1 or USB 2_R Ch 3 R
USB 1 / USB 2_7 CH 4 USB 1 or USB 2_L Ch 4 L
USB 1 / USB 2_8 CH 4 USB 1 or USB 2_R Ch 4 R
USB 1 / USB 2_9 CHA USB 1 or USB 2_L Ch A L
USB 1 / USB 2_10 CHA USB 1 or USB 2_R Ch A R
USB 1 / USB 2_11 CHB USB 1 or USB 2_L Ch B L
USB 1 / USB 2_12 CHB USB 1 or USB 2_R Ch B R
Unlock a world of creative possibilities. The XONE:96 features two Hi-Speed USB connections, each with six
stereo inputs and outputs giving you a myriad of routing options.
State-of-the-art 96kHz/32-bit processing ensures the highest audio quality is passed between your laptops and
the analogue engine.
USB1 and USB 2 operate independently, avoiding hassles for DJs who use different platforms, operating
systems, or projects saved with different preferences, from collaborating live and in the studio.
XONE:96 soundcard channels are arranged in stereo pairs and will be displayed in your chosen Digital DJ, or
DAW software, as follows:
XONE:96 is also fully Traktor Scratch Certified so the internal soundcards bring
support for DVS control of Native Instruments’ flagship TRAKTOR SCRATCH PRO
DJ software straight out of the box.
Refer to p.30 for more details, or visit the Native Instruments website.
For full details of the Dual-USB Soundcard Digital Architecture Specifications, please refer to p.35-36
