Rockwell Automation Publication 1420-UM001E-EN-P - March 2016 55
PowerMonitor 500 Unit Data Tables Appendix A
DMD Metering Values (power, PF, frequency)
Table 21 - Table Properties
CIP Assembly Instance 106
No. of Elements 17
Length in Words 34
Data Type REAL
Data Access Read Only
Table 22 - DMD Metering Values (power, PF, frequency) Data Table
Element Modbus
Address
Length
(words)
Description / Units Data Format Notes
0 300873 2 DMD W L1 REAL
1 300875 2 DMD W L2 REAL
2 300877 2 DMD W L3 REAL
3 300879 2 DMD W REAL
4 300881 2 DMD VA L1 REAL
5 300883 2 DMD VA L2 REAL
6 300885 2 DMD VA L3 REAL
7 300887 2 DMD VA REAL
8 300889 2 DMD VAR L1 REAL Negative values correspond to lead (C), positive values correspond
to lag (L)
9 300891 2 DMD VAR L2 REAL
10 300893 2 DMD VAR L3 REAL
11 300895 2 DMD VAR REAL
12 300897 2 DMD PF L1 REAL
13 300899 2 DMD PF L2 REAL
14 300901 2 DMD PF L3 REAL
15 300903 2 DMD PF REAL
16 300905 2 DMD Hz REAL
