Rockwell Automation Publication 1420-UM001E-EN-P - March 2016 25
Chapter 3
Unit Configuration
Configure with the Display
The PowerMonitor™ 500 unit provides menu-based configuration
(programming) by using its front panel display. The programming menus let you
select parameters to edit, select digits within parameters, and increase or decrease
the value of each digit.
Place the unit in Programming mode by pressing Program/select (8) for about
2 seconds. The front panel displays the PASSWORD? menu page 0 in Editing
mode. Enter the correct password by using the Up and Down arrows (the default
password is 0) and press Program/select. The front panel then displays the
CHANGE PAS menu page 10.
See the programming flowchart that begins on page 28
for a view of the
organization of programming menus and submenus. Each page is identified with
a number, which is displayed in the top right corner. Menu page numbers end in
zero, while submenu pages end in 1 through 9. For example, the Change
Password page is menu 10. Likewise, the Dmd page is menu 80, and the demand
interval Time page is menu 82.
While you are programming the power monitor, the display items and control
buttons function one way when you are navigating between menu or submenu
pages, and another way when you are editing a menu page.
