76 Rockwell Automation Publication 1420-UM001E-EN-P - March 2016
Appendix C PowerMonitor 500 EtherNet/IP Device Profile
Identity Object Class Attributes (Instance 0)
Instance 1 (PowerMonitor 500 device and Communication module)
Instance 1 represents the PowerMonitor 500 device with its EtherNet/IP
module. Instance 1 of the Identity Object is the one that is browsed by RSLinx®
software, relevant to the complete device, that is, the PowerMonitor 500 device
and Communication module.
Instance 1 of the Identity Object reports the following instance-specific attribute
values.
Identity Object Instance 1 Attributes
Attr ID Access Name Data Type Default Value
0x01 Get Revision UINT 1
0x02 Get Max Instance UINT 1
0x03 Get Number of
Instances
(1)
(1) Attribute ID 0x03 is not returned for service type Get Attribute All.
UINT 1
0x06 Get Maximum ID
Number Class
Attributes
UINT 7
0x07 Get Maximum ID
Number Instance
Attributes
UINT 7
Attribute ID Access Name Data Type Value
0x01 Get Vendor ID UINT 1 (Rockwell Automation)
0x02 Get Device Type UINT 0x92 (146d)
0x03 Get Product Code UINT See Product Code Values
table
0x04 Get Revision Struct of: Dynamic (varies with the
communication firmware
revision)
Major Revision USINT
Minor Revision USINT
0x05 Get Status WORD Dynamic
0x06 Get Serial Number UDINT 940000000…950000000
0x07 Get Product Name SHORT_STRING PowerMonitor 500
