108 Rockwell Automation Publication 1734-UM013N-EN-P - September 2017
Chapter 5 Configure the Module in a GuardLogix Controller System
Analog Input Data
Run Mode
STANDARD
Indicates whether consumed data is actively being updated by a device that is in one of these states:
Run mode: 1 Idle State: 0
Connection Faulted
STANDARD
Indicates the validity of the safety connection between the safety producer and the safety consumer.
Valid: 0 Faulted: 1
Safety Input Data
SAFETY
Value of analog input data
Individual Safety Input Status
SAFETY
Indicates the status of each safety input circuit.
Normal: 1 Fault (Alarm): 0
Individual Status - Process Alarms
STANDARD
Indicates whether each Safety Input Data value of a channel is between the configured High and Low
Alarm values.
Normal: 1 Alarm: 0
Individual Status - Fault Reason
STANDARD
Input Point Fault Reason
Individual HH Alarm Status
STANDARD
Individual High High Alarm Status
Normal: 1 Alarm: 0
Individual H Alarm Status
STANDARD
Individual High Alarm Status
Normal: 1 Alarm: 0
Individual L Alarm Status
STANDARD
Individual Low Alarm Status
Normal: 1 Alarm: 0
Individual LL Alarm Status
STANDARD
Individual Low Low Alarm Status
Normal: 1 Alarm: 0
Individual Tachometer Overfrequency
SAFETY
When the input is configured for Tachometer mode, this data indicates an overfrequency condition; that
is, when pulses are faster than 1000 Hz.
Normal: 1 Fault: 0
Individual Tachometer Under-frequency
SAFETY
When the input is configured for Tachometer mode, this data indicates an under-frequency condition;
that is, when pulses are slower than 1 Hz.
Normal: 1 Fault: 0
Individual Tachometer Dual Low
SAFETY
Indicates that both channels are low when the input is configured for Tachometer mode.
Normal: 1 Fault: 0
Input Power
STANDARD
Indicates that input power over- or underrange.
Normal: 1 Fault: 0
Analog Output Data Reset Tachometer
SAFETY
Resets a latched overfrequency condition and enables the module to begin calculating frequency again.
No reset: 0 Reset: 1
Data Description
IMPORTANT
In the previous table, ‘SAFETY’ denotes information the controller can use in
safety-related functions. ‘STANDARD’ denotes additional information that
must not be directly used for safety functions.
ATTENTION: Do not rely on data readback to detect faults. You must monitor
status bits to detect faults.
