Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 153

Replacing POINT Guard I/O Modules Chapter 8

By Using RSNetWorx for DeviceNet Software

Follow these steps to reset the module to an out-of-box condition.

1. Right-click the module and choose Reset Safety Device.

2. Check all options.

3. Click Reset.
