Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 151
Replacing POINT Guard I/O Modules Chapter 8
Figure 49 - Setting the SNN with a GuardLogix Controller
Figure 50 - Setting the SNN with a SmartGuard Controller
Resetting a Module to
Out-of-box Condition
If a POINT Guard I/O module was used previously, clear the existing
configuration before installing it on a safety network.
When using POINT Guard I/O with a See
GuardLogix controller on an EtherNet/IP network By Using the Logix Designer Application
on page 152
GuardLogix controller with 1734-PDN module on a
DeviceNet network
By Using RSNetWorx for DeviceNet Software
on page 153
SmartGuard controller on a DeviceNet network
To Next Page
