Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 143
Configuring Safety Connections between a GuardLogix Controller and POINT Guard I/O Modules on a DeviceNet Network Chapter 7
Verify Your DeviceNet Safety
Configuration
The Safety Device Verification Wizard, which is accessed from RSNetWorx for
DeviceNet software, guides you through the verification of the configuration of
your safety devices and provides the means for safety-locking those devices. The
verification process includes upload and comparison of the configuration that is
stored in the device and the configuration that is stored in the RSNetWorx for
DeviceNet software configuration file. The configuration is displayed in a report
to facilitate visual verification and record keeping.
To run the Safety Device Verification Wizard, follow these steps.
1. Choose Network >Safety Device Verification Wizard.
2. On the Welcome dialog box, click Next.
Before running the Safety Device Verification Wizard, you must browse and
upload your network and test the safety devices and all of their safety
functions on your network to verify that they are operating properly. You must
fully test your application before safety-locking your devices.
Some devices on your network can not support verification by the Safety
Device Verification Wizard. To determine the method that is required for
verifying these devices, consult the user documentation.
