Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 191
Specifications Appendix C
Input filter time, OFF to ON
(3)
0…126 ms (in 6 ms increments)
Input filter time, ON to OFF
(2)
Indicators 1 yellow lock status indicator
1 green/yellow power status indicator
8 I/O channel status indicators
Keyswitch positions (left and right) Key 1 = 8 (left); Key 2 = 1 (right)
North America temp code T4
IEC temp code T4
Enclosure type rating None (open-style)
Wiring category
(4)
2 - on signal ports
Wire size Determined by installed terminal block
Terminal block torque specs Determined by installed terminal block
Weight, approx. 62.4 g (2.2 oz)
Dimensions (HxWxD), approx. (without terminal
block)
77 x 25 x 55 mm (3.03 x 0.98 x 2.17 in.)
(1) Maximum power dissipation applies when using 28.8V DC module supply, 30V DC on all inputs and maximum power dissipated
with all four test outputs in the ON state.
(2) Typical power dissipation applies when using 24V DC module supply, 24V DC on all inputs and nominal power dissipated with all
four test outputs in the ON state.
(3) Input off-to-on filter time is the time from a valid input signal to recognition by the module. Input on-to-off time is the time from a
valid input signal to recognition by the module.
(4) Use this conductor category information for planning conductor routing. See the Industrial Automation Wiring and Grounding
Guidelines, publication 1770-4.1
.
Attribute 1734-IB8S Series B
