Allen-Bradley 1734-OB8S User Manual

Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 53
Chapter 4
Install the Module
Figure 25 - POINT Guard I/O™ Modules
Topic Page
Precautions 54
Install the Mounting Base 57
Connect the Module to the Mounting Base 59
Connect the Removable Terminal Block 60
Remove a Mounting Base 61
Wire Modules 61
Connection Details 65
Wiring Examples 67
Slide-in Writable Label
Insertable I/O Module
31867-M
Module Locking
Mechanism
Mounting Base

Allen-Bradley 1734-OB8S Specifications

General

Brand	Allen-Bradley
Model	1734-OB8S
Category	Control Unit
Language	English
