Page #11 background imageLoading...
Page #11 background image
Publication 1746-5.16
11
3. Make sure the removable terminal wiring block is attached to the module
and all wires are connected to the terminal block.
4. Insert the cable tie in the slots and secure the cable.
5. Cover all unused slots with the Card Slot Filler, Catalog Number 1746-N2.
Removing the Terminal Block
The removable terminal wiring block eliminates the need to rewire a module if it
is removed from the rack. Each terminal accepts two #14 AWG wires.
Remove the terminal block by turning the slotted terminal block release screws
counterclockwise. The screws are attached to the terminal block, so it will follow
as the screws are turned out.
Wiring the Removable Terminal Block
The terminal screws can be turned with flat or cross slot screwdrivers. Each
screw should be turned tight enough to immobilize the wire’s end.
Overtightening can strip the terminal screw. The torque applied to each screw
should not exceed 0.7-0.9 Nm (6-8 inch pounds).
!
ATTENTION: Disconnect power before attempting to install,
remove, or wire the removable terminal wiring block.
To avoid cracking the removable terminal block, alternate the
removal of the slotted terminal block release screws.
