Allen-Bradley 1746-HSCE User Manual

22
Publication 1746-5.16
Outputs (Open Collector, Sinking)
4.5 to 10V dc
(Switch 2 on)
10 to 30V dc
(Switch 2 off)
Max. On-State Output Current
16 mA at 4.5V dc
40 mA at 10V dc
40 mA at 10V dc
125 mA at 30V dc
Max. On-State Voltage Drop 0.4V dc 1.0V dc
Max. Off-State Leakage Current 100
µ A
Isolation (from backplane) 1500 volts
