64 Rockwell Automation Publication 1756-UM013B-EN-P - October 2019
Chapter 4 1756-OBV8S Output Module Features
Fault and Status Reporting
The 1756-OBV8S module multicasts fault and status data with channel data to
the owner and listening controllers. The data is returned via module tags that you
can monitor in your Logix Designer application.
For more information on how to use module tags to monitor fault and status
reporting, see Table 24 on page 71
•Appendix A, Troubleshoot Your Module on page 103.
Module Health Diagnostics
Each output module has a status indicator on the front of the module that
indicates module health. For more information on module health diagnostics, see
Appendix A, Troubleshoot Your Module on page 103
.
