Rockwell Automation Publication 1769-UM021G-EN-P - October 2015 161
Use I/O Modules with CompactLogix 5370 L1 Controllers Chapter 7
The field-side power requirement of the local expansion modules of the
controller is 24V DC nominally with an input range of 10…28.8V DC.
For more information on how to connect a power source to the FP+ and
FP- terminals, see page 144
.
We recommend that you make sure all 1734 POINT I/O modules that
you intend as local expansion modules are upgraded to the most current
firmware revision before installing them in a CompactLogix 5370 L1
control system.
The available RPI range of each local expansion module is 1.0
750.0 ms
and can be changed by 0.5 ms increments. The default setting is module-
dependent.
You can configure RPI values for each local expansion module in your
control system. However, the complete I/O configuration has an impact
on the rate at which data is transmitted in a CompactLogix 5370 L1
control system. For more information, see Estimate Requested
Packet Interval on page 166.
Before installing a 1734 POINT I/O module into a CompactLogix 5370
L1 control system, make sure the I/O module is set to Autobaud. 1734
POINT I/O modules are set to Autobaud by default.
If you must return a 1734 POINT I/O module to Autobaud, see the
POINT I/O Digital and Analog Modules and POINTBlock I/O
Modules, publication 1734-UM001
.
When possible, use specialty 1734 POINT I/O modules to meet unique
application requirements.
Make sure that there are no empty slots between the controller and local
expansion modules or between local expansion modules.
