Allen-Bradley 1769-SDN - Appendix B: 1769-SDN DeviceNet Class Codes

1 Publication 1769-UM009B-EN-P - May 2002
Appendix B
1769-SDN DeviceNet Class Codes
This appendix contains the most commonly used class codes for the
1769-SDN DeviceNet Scanner Module. They are shown in the
following tables.
Table 2.1 DeviceNet Object
Name Class Instance Attribute Data Size Access
MAC ID 0x03 0x01 0x01 1 byte
Get/Set
(1)
(1)
The set also causes a reset.
Baud Rate 0x03 0x01 0x02 1 byte Get/Set
Bus Off Counter 0x03 0x01 0x04 1 byte Get
Table 2.2 Identity Object
Name Class Instance Attribute Data Size Access
Vendor ID 0x01 0x01 0x01 2 bytes Get
Device Type 0x01 0x01 0x02 2 bytes Get
Product Code 0x01 0x01 0x03 2 bytes Get
Revision 0x01 0x01 0x04 2 bytes Get
Status 0x01 0x01 0x05 2 bytes Get
Serial Number 0x01 0x01 0x06 4 bytes Get
Product Name 0x01 0x01 0x07 9 bytes Get
